Pyramid Tea Bag Packing Machine (volumetric weighing system)Pyramid Tea Bag Packing Machine (volumetric weighing system)Pyramid Tea Bag Packing Machine (volumetric weighing system)

Model number: API146andVSD50

  • Two different kinds of tea bags : You can easily change the packing type between pyramid and rectangular with one click.
  • Ultrasonic : Ultrasonic sealing is more safe, efficient and eco-friendly. The machine is equipped with overload protection and alarm.
  • Touch screen : You can easily operate the machine with touch screen panel. It provides comprehensive setting function.
  • Our machine equipped with quick clean device. Easy to change ingredient.
  • Parts contacted with ingredient are all made by stainless steel.
  • Volumetric weighing system is suitable for granule such as tea fanning, ground coffee…etc. It’s easy to adjust within the range.
  • You can have more selection of material such as PET/ Nylon mesh, bio-degradable materials.
Inquiry
Quantity
  • Capacity : Max. 60 bag/min. Packing speed is different according to different size and filling weight.
  • Packing Material : Non woven , Nylon/PET mesh, PLA...etc.
  • Packing Method : Sealing and cutting by ultrasonic.
  • Bag Size : Pyramid: 55-78mm ; Plane : L45-100mm W58-78mm
  • Weighing System : Slide doser volumetric weighing system. Easy to adjust
  • Filling Range : 13cc-63cc, Weighing range will be different according to different ingredient.
  • Power Supply : AC220V,50/60Hz,3P,3.0KW (Can be transformed to local voltage)
  • Compressed Air : 5Kg/c㎡ (0.5MPa)
  • Dimension : 1100mm(L)x750mm(W)x2165mm(H)
  • Weight : 320 Kg
  • Standard Accessories : Touch panel HMI; Static Ionizing Generators ; Tag detector ; Ultrasonic overload protection ; Fluidizer to prevent bridging ; Liner & waste collection device.
  • Option : Conveyer
Pyramid Tea Bag Packing Machine (volumetric weighing system)
Dust tea

Pyramid Tea Bag Packing Machine (volumetric weighing system)Ground coffee
